Power supply +5VDC 10%
Current consumption <100mA
Interface USB
Swipe Method F2F (two-frequency coherent phase) complied with ISO and JIS
standard
Swipe Speed 5 to 60 inch/sec.
Track 1, IATA Standard
Track 2, ABA Standard
Track 3, THRIFT Standard
JIS- , JIS x 6301 Standard
Track 1 .79 characters (7 bit code)
Track 2 .40 characters (5 bit code)
Track 3 .107 characters (5 bit code)
JIS- ...79 characters (7 bit code)
TMSR Size 96.5mm(L) x 30.5mm(W) x 32.2mm(H)
Weight 101.3g
Cable length 1.5M
Head life
1,000,000 passes version can be requested
MMSR Size 100mm(L) x 33.8mm(W) x 28.3mm(H)
Weight 118.9g
Cable length 1.5M
Head life 300,000 pass minimum
Storage temperature -20 to +60
Operating temperature 0 to +50
Operating humidity 20% to 90%
Card Standard
Card Density
300,000 pass minimum
1,000,000 passes version can be requested
