Form Factor MicroATX (9.60 inches by 7.80 inches [243.84 millimeters by
198.12 millimeters])
Processor • Intel® Core™ i7, Intel® Core™ i5, Intel® Core™ i3, and Intel®
Pentium®
processors in an LGA1155 socket with up to 95 W TDP:
? Integrated graphics processing (processors with Intel® Graphics
Technology)
? External graphics interface controller
? Integrated memory controller
Chipset Intel® H61 Express Chipset consisting of the Intel® H61 Platform
Controller
Hub (PCH)
Memory • Two 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets
• Support for DDR3 1333 MHz and DDR3 1066 MHz DIMMs
• Support for 1 Gb, 2 Gb, and 4 Gb memory technology
• Support for up to 8 GB of system memory with two DIMMs using 4 Gb
memory
technology
• Support for non-ECC memory
Graphics • Integrated graphics support for processors with Intel® Graphics
Technology
• Discrete graphics support for PCI Express 2.0 x16 add-in graphics card
Audio • Intel® High Definition Audio:
? Realtek* ALC892 audio codec
? S/PDIF audio header
? Front panel audio header
Peripheral
Interfaces
• Six USB ports:
? Four USB 2.0 ports are implemented with stacked back panel connectors
? Two USB 2.0 front panel ports are implemented through one dual-port
internal header
• Four SATA interfaces through the Intel H61 Express Chipset
• One serial port header
• One parallel port connector on the back panel
• One PS/2* keyboard/mouse port on back panel
Legacy I/O Control • Nuvoton* W83677HG-i Super I/O controller for hardware
management and
serial port, parallel port, and PS/2 support
BIOS • Intel® BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and
Play,
and SMBIOS
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.2
• Support for PCI Express*
• Suspend to RAM support
• Wake on Conventional PCI, PCI Express, LAN, front panel, serial, PS/2, and
USB ports
LAN Support Gigabit (10/100/1000 Mbits/s) LAN subsystem using the Intel®
82579V Gigabit
Ethernet Controller
Expansion
Capabilities
• One PCI Express 2.0 x16 add-in card connector
• One PCI Express 2.0 x1 add-in card connector
• One Conventional PCI bus connector
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton Super I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Two fan headers
• Two fan sense inputs used to monitor fan activity
• Fan speed control
